Marine

Marine switches and circuit protection for yachts, cabin cruisers, ski boats, pontoons, fishing boats, sail boats and more.

Marine Switches, Battery Disconnects and Circuit Protection

With decades of design and manufacturing experience, Carling Technologies is the market leader in marine application switches, battery disconnects, circuit breakers and ELCIs. From small boats to luxury yachts, OEM design engineers trust our products not only for their style but also for their performance. Carling's switches are widely used and the most recognizable switch brand in the industry with unmatched quality and aesthetics. Our circuit breakers and ELCIs are guaranteed to perform under extreme marine environments while keeping boats and boaters safe from electrical currents. By drawing upon over a century of design experience, Carling Technologies is also able to provide custom product solutions sure to meet the most stringent design requirements.

Marine Rocker Switches

HR-Series Halo Illuminated Sealed Rockers

Low profile actuator available in either two or three positions with a variety dependent and independent illumination options. Up to two customizable laser-etched legends per switch. Available in one or two poles; 20A 12V.

V-Series Contura® II, III Sealed Rockers

Snap-in rockers with “Soft Touch” Elastomer overlay featuring either raised bumps or 3 rows of rigged finger traction on top and bottom of rocker. Square and bar lenses Available in one or two poles; 15/20A,12/24VDC; 10/15A, 125/250VAC.

V-Series Contura® IV, V, VII Sealed Rockers

Snap-in rockers with gloss or matte texture. These actuator offerings have varying curved styles that can be mounted several ways. Oval and elliptical lenses. Available in one or two poles; 15/20A,12/24VDC; 10/15A, 125/250VAC.

V-Series Contura® VI Sealed Rockers

Snap-in rockers when used in a row, create a unique wave style. Replaceable wave inserts available in black, white, chrome/nickel plated, and chrome painted. Oval and elliptical lenses. Available in one or two poles; 15/20A,12/24VDC; 10/15A, 125/250VAC.

W-Series Submersible Rockers

Features complete IP68 protection, even below the panel, where the critical connection is made from your wiring harness. Dual level and multicolor LEDs, progressive and hazard warning circuits. Available in one or two poles; ratings up to 10A 24V.

Marine Pushbutton Switches

AV/AVH-Series Sealed Pushbutton

Sleek stainless steel with LED Halo illumination Single pole with maintained or momentary circuits. AVH offers progressive circuits for NAV/ANCHOR functions. AV-Series: 10.1A 12VDC and AVH-Series: Up to 30A 12VDC.

P26-Series Single Pole Pushbutton

Single throw momentary action, AC rated up to 6A 125VAC and suitable for shallow back panel applications. Nylon or metal button styles.

P27-Series

Single throw momentary action, AC rated up to 6A 125VAC; 3A 250VAC and suitable shallow back panel applications. Concave nylon button style.

Marine Toggle Switches

LT-Series Lighted Toggle

Three-color lighting sequence from a single lamp and neoprene bushing seals for dust/moisture protection. Available in one or two poles; Up to 15A.

ST-Series Metal Toggle

Toggle seal composed of dynamic silicone material that bonds to the metal toggle, pin and bushing, providing ideal sealing and protection against the environment, vibration and shock, while withstanding extreme temperature variations.

F-Series Single Pole Toggle

Metal bat toggle available in sealed or unsealed styles. AC rated, but also suitable for low voltage DC applications. Rated up 20A 277VAC; 1 HP 120/240VAC.

G-Series One/Two Pole Toggle

Metal bat toggle or nylon paddle available in sealed or unsealed styles. AC rated, but also suitable for low voltage DC applications. Rated up 20A 125/277VAC; 2 HP 250VAC.

Marine Battery Disconnect Switches

Battery Disconnect Switches

Designed to minimize battery drain, ensure maintenance personnel safety and provide theft protection. Two single pole styles available, up to 250A or 300A; 12/24VDC.

Marine Circuit Breakers
Hydraulic-Magnetic

A-Series

Compact breaker perfect for marine panels in boats. Various actuator styles for flexibility in design and functionality. Available in one to six poles with UL 1077, UL 1500, CSA, TUV and VDE approvals, ratings from 0.02 to 50 amps, 277VAC/80VDC and 7,500 amps max IC.

B-Series

Compact breaker with construction that provides the necessary spacing requirements for global regulatory safety approvals. Available in one to six poles for handle styles and one to three poles for rocker styles with UL 489, UL 489A, UL 1077, UL 1500, UL 508, cULus, CSA, TUV and VDE approvals, ratings from 0.02 to 50 amps, 277VAC/80VDC and 7,500 amps max IC.

C-Series

Compact yet robust, and ideally designed for high amperage and voltage applications. C-Series features thermoset glass-filled polyester half shell construction. Available in one to six poles with UL 489, UL 1077, UL 1500, CSA, TUV and VDE approvals, ratings up to 100 amps for 480VAC/80VDC or 240VAC/125VDC for UL 489 configurations.

H-Series

Compact breaker, meeting IEC spacing requirements for global market applications. Available in one to three poles offering UL 1077, CSA, TUV and CCC approvals with ratings from 0.1-35 amps, 250VAC/65VDC or 80VDC for single pole configurations. 3,000 amps max IC.

J-Series

Compact, low profile breaker featuring 10,000 amps maximum IC, making it ideal for marine applications requiring high interrupting capacity. Available with UL 489, cULus, and TUV approvals with ratings from 1 to 20 amps, up to 240VAC. Max IC of 10,000 amps; 5,000 amps TUV.

M-Series

High performance miniature circuit breakers are front panel mounted, offer multiple configuration options for design flexibility and wiping contacts for long-term reliability. Available in one or two poles with UL 1077, CSA, TUV and VDE approvals with ratings from 0.02 to 30 amps, up to 125/250VAC or 80VDC. 1,000 amps max IC; 600 amps TUV and 500 amps VDE.

Thermal

CLB-Series

Plastic or metal bushing construction with multiple hardware options and hex boots. Agency approvals include UL 1077, cUL, UL 1500/ISO 8846, TUV and CE. Single pole with ratings from 3-60 amps, 125/250VAC, 32VDC. 1,000 AIC at 250VAC and 2,500 AIC at 32VDC.

CMB-Series

Plastic or metal bushing construction with multiple hardware options and hex boots. Agency approvals include UL 1077, cUL, UL 1500/ISO 8846, TUV and CE. Single pole with ratings from 3-20 amps, 125/250VAC, 32VDC. 1,000 AIC at 250VAC and 2,500 AIC at 32VDC.

C1005B-Series

Circuit protector and switch in compact design with lighted or unlighted rocker actuator. Snap-in mount. Approvals include UL 1077, cUL and TUV certified to IEC 60934. Single pole, 7-16 amps, 125/250VAC, 32VDC. 1,000 AIC.

CTB-Series

Compact, rocker actuated breaker that fits panel thickness range from .032” - .100”. Snap-in mount. Agency approvals include UL 1077, cUL, VDE and CE. Single pole with ratings from 3-16 amps, 125VAC, 250VAC, 125/250VAC, 50VDC. 1,000 AIC.

GFCI/ELCI

PB-Series

An AC Residual Current Circuit Breaker with Overcurrent Protection (RCBO). It increases safety around boats and marinas, protecting against electrical shock hazards near water.

PC-Series

An AC Residual Current Circuit Breaker with Overcurrent Protection (RCBO). The PC-Series also features two LED status lights and is configurable in one to three poles with ratings up to 50 amps, 120VAC, 120/240VAC and 5,000 amps max IC. UL 1053 Recognized, cRUus, and UL 1500 Ignition Protection agency approvals.

Download: Marine Industry Brochure
