C11-B0-14-680-311-R

Category: C-Series

Submit Request	Estimated Annual Quantity
	Application	I want a quote. I want a sample.

Line Drawing - Click to Enlarge

Current Rating	80 amp
Poles	1
Trip Time Delay	DC Medium
Circuit	Series Trip (Current)
Mounting	6-32 x 0.195" Standard Rocker Bezel
Termination	Stud 1/4-20
Actuator Type	Two Color Flat Visi-Rocker
Illumination	Non-Illuminated
Agency Approvals	UL 1077 Recognized\|CSA Accepted\|TUV Certified to IEC/EN 60934\|UL 489 Recognized
Group	Circuit Protection
Series	C-Series
Product Type	C-Series Circuit Breaker
3D CAD	Yes
