Line Drawing - Click to Enlarge
Product Details
| Current Rating |
50 amp |
| Voltage |
120VAC |
| Poles |
1 |
| Trip Time Delay |
50/60Hz Medium |
| Interrupting Capacity |
5,000 amps |
| Circuit |
Series Trip (Current) |
| Mounting |
6-32 x 0.195" Threaded Insert, with barriers |
| Termination |
Stud 10-32 |
| Actuator Type |
Handle |
| Illumination |
Non-Illuminated |
| Agency Approvals |
UL 1077 Recognized|UL 1053 Recognized Component|CSA Recognized Component |
| Current Leakage |
30mA |
| Group |
Circuit Protection |
| Series |
PC-Series |
| Product Type |
Equipment Leakage Circuit Interrupters |
| 3D CAD |
Yes |
